Caterpillar bearing 5P-9177 suitable：Bulldozer D5, D6D.
Brand:
ZHZBItem NO.:
5P-9177Payment:
T/T ; Western Union; MoneygramProduct Origin:
CHINAShipping Port:
Guangzhou,Qingdao,Shanghai,Ningbo,ShenzhenLead Time：
1-2 Work dayCaterpillar Bulldozer Bearing 5P-9177
|
P/N |
5P-9177 |
Material: |
GCR15 |
|
i/d |
mm |
O/D |
mm |
|
H |
mm |
Brand： |
ZHZB |
|
Precision |
P0 , P6 , P5 |
Structure: |
Cylindrical Roller Bearing |
| Minimum order quantity | Negotiable | market price | Negotiable |
High-quality bearing steel, wear-resistant and anti-impact
Production Process:
YOUTUBE
Product Photos
Chinese bearing manufacturer, Gcr15 material, P0/P6/P5 precision grades optional
Stable performance for harsh construction conditions
Ready stock, fast delivery, professional aftermarket support
Any other parts for the final drive gearbox system you need pls search from below picture and form list then mark to me we will quote to you
Pos.
Part No
Qty
Parts name
1
3T-1898
[2]
DRUM (120-TEETH)
2
7X-0345
[40]
BOLT (5/8-11X1.75-IN)
3
8T-4122
[40]
WASHER-HARD (17X32X3.5-MM THK)
4
9P-0418
[2]
CAGE
5
0L-1026
[6]
PLUG-CUP
6
3F-1953
[6]
DOWEL
7
5P-9176
[4]
BEARING
8
5P-7143
[2]
SEAL GP-DUO-CONE
9
5P-9177
[4]
RACE-BEARING INNER
10
6V-0530
[2]
NUT (1-3/4-12-THD)
11
3P-7236
[2]
GASKET
12
7G-6986
[2]
LOCK
13
8T-9397
[4]
BOLT (3/4-10X1.25-IN)
14
7X-0521
[4]
WASHER-HARD (20X36.5X5-MM THK)
15
3P-6318
[2]
FLANGE-DRUM
16
5P-2566
[68]
BOLT (1/2-13X1.5-IN)
17
7X-3392
[24]
WASHER-HARD (13.5X22.5X3-MM THK)
18
1S-4974
[2]
SEAL-O-RING
19
5M-7383
[2]
CAGE
20
6V-1013
[2]
BEARING
21
6V-1014
[2]
RACE-BEARING INNER
22
3H-4174
[2]
DOWEL
23
9P-9360
[2]
GEAR (35-TEETH)
24
9P-9362
[2]
PINION (11-TEETH)
25
5P-5066
[2]
BEARING-OUTER
26
5P-5067
[2]
RACE-BEARING INNER
27
8P-8914 Y
[2]
SPROCKET GP (SEGMENTED)
28
6T-8439
[4]
SEAL GP-DUO-CONE
(EACH INCLUDES)
2M-0344
[2]
RING-SEALING
29
6B-4844
[2]
GUARD
30
5M-3062
[10]
BOLT (3/8-16X0.75-IN)
31
8T-4896
[10]
WASHER-HARD (10.2X18.5X2.5-MM THK)
32
2B-8091
[2]
RING-RETAINING
33
2B-7906
[2]
PIN
34
5M-2130
[2]
NUT
35
5M-6670
[2]
SHAFT-SPROCKET
36
9W-8929
[2]
RETAINER-SEAL
37
4B-1281
[16]
SCREW-MACHINE (1/4-20X0.625-IN)
38
128-8561
[2]
HUB-FINAL DRIVE
39
3B-4990
[36]
BOLT (5/8-18X2-IN)
40
2S-8415
[36]
WASHER (0.683X1.11X0.075-IN THK)
41
2K-4821
[36]
LOCKNUT (5/8-18-THD)
42
4M-7432
[2]
RING
43
118-8605
[2]
BEARING AS
44
134-6261
[2]
BEARING-SPECIAL
45
9P-9361
[2]
GEAR-FINAL DRIVE (46-TEETH)(46 TEETH)
46
9P-0566
[1]
CASE-FINAL DRIVE (RH)
47
9P-0567
[1]
CASE-FINAL DRIVE (LH)
48
3S-9182
[2]
PLUG-MAGNETIC
49
6P-9609
[2]
GASKET
50
5M-6637
[1]
BUSHING
7T-0341
[1]
SUPPORT
51
2P-3421
[2]
RETAINER
52
146-5808
[2]
CAP-BEARING
53
2S-4364
[1]
RETAINER
0S-0130
[2]
PIN
54
5M-6628
[2]
LOCK
55
7F-2339
[2]
NUT (1-3/4-12-THD)
56
1B-8742
[2]
KEY-WOODRUFF
57
2S-4366
[8]
SHIM (0.915-MM THK)
58
9S-8005
[2]
PLUG (3/4-16-THD)
59
3K-0360
[2]
SEAL-O-RING
60
9W-7989
[2]
SEAL
61
2B-7557
[6]
CORK
62
2B-8162
[6]
DOWEL
63
8T-9391
[8]
BOLT (1/2-13X3.75-IN)
64
8C-4436
[12]
BOLT (1/2-13X1.375-IN)
65
193-0349
[2]
SPACER (121.22X155.45X18-MM THK)
66
118-0028
[2]
NUT (4-3/4-12-THD)
67
118-0029
[2]
RETAINER
68
118-0031
[2]
HOLDER AS
9M-4007
[2]
DOWEL
69
135-6036
[2]
LOCK
70
132-3837
[2]
RACE-SPECIAL ROLLER
71
2M-0849
[64]
WASHER-HARD (13.5X25.5X5-MM THK)
72
2M-4480
[2]
RING
73
9P-9363
[2]
PINION (9-TEETH)
